HARDYVOX®

Aluminum body for wall installation, IP66 et IK10

HARDYVOX® is a hands-free industrial telephone, consisting of a die-cast aluminum body of exceptional resistance (1 cm thick), with IP66 protection rating. The buttons are made of aluminum and there is a status indication LED. All external parts of the phone are impact-resistant with IK10 grade. It is supplied in analog, VoIP or GSM version. It is compatible with the Smart option package, which includes automatic tests (AFD) and remote interrogation. There are numerous SMART functions performed by this phone, including automatic answer after a predefined number of rings, repetition of the call via optical and acoustic and external devices, activation of relays when entering a DTMF password, automatic entry of pre-stored numbers (automatic dialing).

TEL487T
with keypad

TEL487T is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for memorized numbers that can be recalled with the Fn key. It is available in Analog, VoIP and GSM versions. It is generally used for service communications and to authorize entry into departments and buildings, thanks to the optional remote-controlled relays.

  • Body Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad 15 Aluminium Ø 13mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order Codes
  • TEL487T analog
  • TEL487TSm analog Smart
  • TEL487T-VoIP VoIP (SIP)
  • TEL487T-VoIP-Sm VoIP (SIP) Smart
  • GSM487T GSM
  • GSM487TSm GSM Smart

TEL487M1
1 button

TEL487M1 has only one metal button for calling pre-stored numbers. It is available in Analog, VoIP and GSM versions. It is generally used for emergency and service communications and to authorize entry into departments and buildings, thanks to the remote-control relays available as an option.

  • Body Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Button Aluminium Ø 20mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order Codes
  • TEL487M1 analog
  • TEL487M1Sm analog Smart
  • TEL487M1-VoIP VoIP (SIP)
  • TEL487M1-VoIP-Sm VoIP (SIP) Smart
  • GSM487M1 GSM
  • GSM487M1Sm GSM Smart

TEL487M4
4 buttons

TEL487M4 is equipped with 4 metallic buttons for calling pre-stored numbers. It is available in Analog, VoIP and GSM versions. It is generally used for emergency and service communications and to authorize entry into departments and buildings, thanks to the remote-control relays available as an option.

  • Body Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad Aluminium Ø 13mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order codes
  • TEL487M4 analog
  • TEL487M4Sm analog Smart
  • TEL487M4-VoIP VoIP (SIP)
  • TEL487M4-VoIP-Sm VoIP (SIP) Smart
  • GSM487M4 GSM
  • GSM487M4Sm GSM Smart

TEL487M8
8 buttons

TEL487M8 is equipped with 8 metallic buttons for calling pre-stored numbers. It is available in Analog, VoIP and GSM versions. It is generally used for emergency and service communications and to authorize entry into departments and buildings, thanks to the remote-control relays available as an option.

  • Body Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad Aluminium Ø 13mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order Codes
  • TEL487M8 analog
  • TEL487M8Sm analog Smart
  • TEL487M8-VoIP VoIP (SIP)
  • TEL487M8-VoIP-Sm VoIP (SIP) Smart
  • GSM487M8 GSM
  • GSM487M8Sm GSM Smart
