ROBUSTPHONE®

Rugged, recessed/wall mounting IP42

ROBUSTPHONE® is a rugged indoor telephone, suitable for wall or recessed installation, made of aluminum with IP42 protection degree and IK08 impact resistance. The keyboard is made of polycarbonate. The handset built in die-cast aluminum is equipped with a traction-resistant stainlesssteel cord> 200kg. The ringtone reaches 95dB at 1 meter. ROBUSTPHONE® has the same quality and resistance to impacts common to our entire range of industrial telephones, although with a degree of protection against the penetration of liquids and dusts that do not allow outdoor installation. The SMART versions are equipped with numerous additional functions, as well as the Automatic Fault Detection (AFD).

TEL146TP
for wall with keypad

TEL146TP is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for short numbers that can be recalled with the Fn key. Suitable for wall installation, it is available in analog, VoIP and GSM versions.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP42 – IK08
  • Temperature -20°C +60°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order Codes
  • TEL146TP analog
  • TEL146TPSm analog Smart
  • TEL146TP-ip VoIP (SIP)
  • TEL146TP-ip-Sm VoIP (SIP) Smart

TEL146M0P
for wall without keypad

TEL146M0P has no keyboard and is designed to perform the service auto-dialing and Hot-Line. Suitable for wall installation, it is available in analog, VoIP and GSM version.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP42 – IK08
  • Temperature -20°C +60°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Bell 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order Codes
  • TEL146M0P analog
  • TEL146M0PSm analog Smart
  • TEL146M0P-ip VoIP (SIP)
  • TEL146M0P-ip-Sm VoIP (SIP) Smart

TEL146TF
recessed with keypad

TEL146TF is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for short numbers that can be recalled with the Fn key. Suitable for wall installation, it is available in analog, VoIP and GSM versions.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP42 – IK08
  • Temperature -20°C +60°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Bell 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order codes
  • TEL146TF analog
  • TEL146TFSm analog Smart
  • TEL146TF-ip VoIP (SIP)
  • TEL146TF-ip-Sm VoIP (SIP) Smart

TEL146M0F
recessed no keypad

TEL146M0F has no keyboard and is designed to perform the service auto-dialing and Hot-Line. Suitable for wall installation, it is available in analog, VoIP and GSM version.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP42 – IK08
  • Temperature -20°C +60°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Bell 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order Codes
  • TEL146M0F analog
  • TEL146M0F Sm analog Smart
  • TEL146M0F-ip VoIP (SIP)
  • TEL146M0F-ip-Sm VoIP (SIP) Smart
