STEELVOXMini™

STEELVOX-Mini™ is a compact hands-free industrial telephone designed for recessed or wall mounting. Its exceptionally robust stainless-steel body provides IP66 protection, while all external components offer high impact resistance up to IK10. The unit features aluminium push-buttons and a status LED.

STEELVOX-Mini™ is available in analogue and VoIP (SIP) versions and supports the SMART option package, including Automatic Fault Detection (AFD) and remote monitoring.

SMART functions include automatic answering after a predefined number of rings, external visual and acoustic call signalling, remote relay activation via DTMF codes and automatic dialling of pre-programmed numbers.

TEL248T
Keypad

PDF icon TEL248T

TEL248T is equipped with a polycarbonate keyboard with 15 dual-function buttons, with 8 memories for short numbers that can be recalled with the Fn key. It is available in the Analog version. It is generally used for service communications and to authorize entry into departments and buildings, thanks to the optional remote-controlled relay.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad Polycarbonate 15 buttons
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote controlled relay
  • Booster amplifier (95dB)
Order Codes
  • TEL248T analog
  • TEL248TSm analog Smart

TEL247M1
1 button

PDF icon Analog
PDF icon VoIP (PoE)

TEL247M1 is equipped with a single metal button for calling pre-stored numbers. It is available in the Analog version. It is generally used for service communications and to authorize entry into departments and buildings, thanks to the remote-controlled relays available as an option.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Aluminium button Ø 20mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote-controlled relay
  • Booster amplifier (95dB)
Order Codes
  • TEL247M1 (Analog)
  • TEL247M1-Sip (VoIP PoE)

TEL247M2
2 buttons

PDF icon Analog

TEL247M2 is equipped with 2 metal buttons for calling pre-stored numbers. It is available in the Analog version. It is generally used for service communications and to authorize entry into departments and buildings, thanks to the remote-controlled relays available as an option.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Aluminium buttons Ø 20mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote controlled relay
  • Booster amplifier (95dB)
Order codes
  • TEL247M2 analog
  • TEL247M2Sm analog Smart

SPECIAL FUNCTIONS

Versions with Induction Loops are available for coupling with hearing aids that work with induction coils, in compliance with the IEC 60118-4 standard.

EMC/EMI

Even the devices of the STEELVOX® range are compliant with the most stringent regulations on electromagnetic compatibility, including specific rules for the railway and electromedical environment

special versions

STEELVOX® and STEELVOX-Mini® can be easily customized in terms of the type and number of buttons, front plate dimensions, graphics and symbols, allowing the units to be adapted to specific applications.

Our technical team is available to help define the most suitable solution for your requirements.
